HZTO400SR4
￥999

型号：HZTO400SR4

加入购物车

产品特征

PAM4 data rate per channel is up to 106.25 Gbps

Supports 400GAUI-4 electrical interface

Integrated 850nm VCSEL array and PD array

DDM Function Implementation

Hot-swappable

Single power supply 3.3 V power supply

  • 商品详情
  • 资料下载(PDF)

光模块01

光模块02

光模块03

This product is a 400 Gb/s OSFP400 400 G SR4 optical module, specifically designed for 100 optical communication applications. The module converts 4 channels of 100Gb/s (PAM4) electrical input data into 4 channels of parallel optical signals, with each channel capable of operating at a total data rate of 100Gb/s.

At the receiving end, the module converts 4 channels of 100Gb/s parallel optical signals into 4 channels of 100Gb/s (PAM4) electrical output data, with the total data rate of each 100Gb/s channel being 400Gb/s.

An optical cable with a single PO-12 connector can be inserted into the OSFP400 400G SR4 module socket. The host FEC needs to support fiber optic transmission up to 100M.


Applications

• Data centers and cloud networks

standard

• Compliant with OSFP MSA5.0

• Compliant with CMIS5.1

• 4 x 106.25 Gb/s electrical interfaces (400GAUI-4)

• Maximum power consumption 8W

• Single +3.3 V power supply

• Case temperature range: 0~+70℃

• RoHS2.0


Order Information

Part number

Product Description

HZTO400SR4

OSFP400 400G SR4Optical module
