HZTO800SR8
￥999

型号：HZTO800SR8

加入购物车

产品特征

PAM4 data rate per channel is up to 106.25 Gbps

Supports 800GAUI-8 electrical interface

Integrated 850nm VCSEL array and PD array

DDM Function Implementation

Hot-swappable

Single power supply 3.3 V power supply

  • 商品详情
  • 资料下载(PDF)

光模块01

光模块02

光模块03

This product is an 800Gb/s OSFP800SR8 optical module designed specifically for 100-meter optical communication applications. The module converts 8 channels of 100Gb/s (PAM4) electrical input data into 8 channels of parallel optical signals, with each channel capable of operating at a speed of 100Gb/s, resulting in an overall data rate of 800Gb/s.

At the receiving end, the module converts 8 channels of 100Gb/s parallel optical signals (with an aggregate data rate of 800Gb/s across all channels) into 8 channels of 100Gb/s (PAM4) electrical output data.

Optical cables with MTP/MPO-16 connectors can be plugged into the OSFP800 SR8 module socket. The host FEC needs to support fiber optic transmission up to 100 meters.


Applications

• Data centers and cloud networks

Standard

• Compliant with OSFP MSA5.0

• Compliant with CMIS5.1

• 8 x 106.25 Gb/s electrical interfaces(800GAUI-8)

• Maximum power consumption 14W

• Single +3.3 V power supply

• Case temperature range: 0~+70℃

• RoHS2.0 compliant


Order Information

Model

Explanation

HZTO800SR8

OSFP800 800G SR8 Optical module

光模块04

光模块05

光模块06
