This product is a 400Gb/s QSFP112 optical fiber, suitable for 5-kilometer communication applications. The module converts 4 channels of 100Gb/s (PAM4) electrical input data from 4 parallel channels into optical signals, each capable of operating at an aggregated data rate of 100Gb/s, totaling 400Gb/s. On the receiver side, the module converts 4 parallel optical signal channels of 100Gb/s (with a total data rate of 400Gb/s for all channels) into 4 channels of 100Gb/s (PAM4) electrical output data. MTP/MPO-12 optical fiber cable connectors can be inserted into the QSFP112DR4 module socket. Host FEC support is required for optical fiber transmission up to 0.5km.

Features

• Compliant with IEEE Standard 802.3ck and IEEE Standard 802.3bs

• Compliant with 400Gbase-DR4 optical specifications

• Compliant with QSFP112 MSA Version 2.0 type

• QSFP112 Type 2 (87.4mm) form factor

• Compliant with CMIS5.1 management interface specification

• MPO12 socket with APC end face

• 4x106.25Gb/s electrical interface (400GAUI-4)

• Transmission up to 0.5km over single-mode fiber (SMF) with FEC

• Single +3.3V power supply

• Case temperature range: 0~+70℃

• Maximum power consumption 10W

Feature

• Compliant with QSFP112 MSA Version 2.0

• 4 parallel optical channels

• Compliant with IEEE 802.3bs 400GBASE-DR4 specification

• Maximum power consumption of 10W

Applications

• 400G Ethernet

• Data Center Interconnect

• Infiniband Interconnect

• Enterprise Network

Order Information
