HZTF800SR8
￥12500

型号：HZTF800SR8

加入购物车

产品特征

Complies with QSFP-DD/QSFP-DD800/QSFP112 hardware version 6.2

Compliant with CMIS 4.0 standard

Eight parallel optical channels

OM4 MMF transmission speed can reach 100m

Compliant with IEEE 802.3db 800GBASE-SR8 specification

Maximum power consumption 14W

MPO-16 Socket

Single 3.3V power supply

Enclosure temperature range: 0~70℃

RoHS 2.0

  • 商品详情
  • 资料下载(PDF)

光模块01

光模块02

光模块03

This product is a 800Gb/s QSFP-DD800 SR8 optical module communication application specially designed for 100m optical fibers. The module converts 8 100Gb/s (PAM4) electrical input channels to transmit data to 8 parallel optical signal channels, with each channel having an aggregated speed of 100Gb/s and a data rate of 800Gb/s. On the receiver side, the module converts 8 parallel optical signals, each at 100Gb/s, converting the aggregated data rate of 800Gb/s into 8 100Gb/s (PAM4) electrical channel output data. Fiber optic cables with MTP/MPO-16 connectors can be plugged into the QSFP-DD800 SR8 module socket. The host FEC needs to support fiber optic transmission up to 100 meters.


Applications

• 800G Ethernet

• Data Center Interconnect

• Enterprise Network


Order Information

Model

Explanation

HZTF800SR8

QSFP-DD800 800G SR8

光模块04光模块05

光模块06
