HZAS25Ax
￥160

型号：HZAS25Ax

加入购物车

产品特征

Hot-swappable SFP28 form factor

Supports a 25.78125 Gb/s bit rate

The maximum link length on OM MMF is 70m

OM4 MMF is 100m 850nm

VCSEL laser and PIN photodetector

Operating temperature range: 0~70℃

Internal CDR on transmitter and receiver channels

Operating temperature range: 0~70℃

Single-channel 3.3V power supply

Low power consumption: <1.0W

  • 商品详情
  • 资料下载(PDF)

光模块01

光模块02

光模块03

Applications

• Data center

• 25GBASE-SR Ethernet

• Infiniband EDR applications

• 32G Fibre Channel applications

• Servers, switches, storage, and host bus adapters

Standard

• Compliant with SFF-8024 and SFF-8431

• Compliant with IEEE802.3by standard

• Compliant with SFF-8472 standard

• RoHS specifications

Order Information

Part. No

Specifications


Pack

Rate

(Gbps)

Tx

(nm)

Rx

Temp

(℃)

Reach

(m)

Fiber

Type

Pull Tab Color

Others

HZAS25A3

SFP28

25.78125

VCSEL

PIN

0~+70

3

OM3

PANTONE Black C

RoHS

HZAS25A5

SFP28

25.78125

VCSEL

PIN

0~+70

5

OM3

PANTONE Black C

RoHS

HZAS25A7

SFP28

25.78125

VCSEL

PIN

0~+70

7

OM3

PANTONE Black C

RoHS

HZAS25A10

SFP28

25.78125

VCSEL

PIN

0~+70

10

OM3

PANTONE Black C

RoHS

HZAS25A70

SFP28

25.78125

VCSEL

PIN

0~+70

70

OM3

PANTONE Black C

RoHS

HZAS25A3

SFP28

25.78125

VCSEL

PIN

0~+70

3

OM4

PANTONE Black C

RoHS

HZAS25A5

SFP28

25.78125

VCSEL

PIN

0~+70

5

OM4

PANTONE Black C

RoHS

HZAS25A7

SFP28

25.78125

VCSEL

PIN

0~+70

7

OM4

PANTONE Black C

RoHS

HZAS25A10

SFP28

25.78125

VCSEL

PIN

0~+70

10

OM4

PANTONE Black C

RoHS

HZAS25A70

SFP28

25.78125

VCSEL

PIN

0~+70

70

OM4

PANTONE Black C

RoHS

HZAS25A100

SFP28

25.78125

VCSEL

PIN

0~+70

100

OM4

PANTONE Black C

RoHS

*Note:

1. Measurement is performed using the PRBS 2-1 test pattern, @25.78125Gb/s, BER<5E-5.

2. 0M3 cable length = <70m or OM4 cable length = <100m.

3. For more detailed product selection and cable lengths, please contact MNC.
