首页 > Optical Module > 1G/10G/25G/40G/100G Optical Modules & Cables > 1G
HZTS1SR
￥32

型号：HZTS1SR

加入购物车

产品特征

Hot-swappable

1.25Gbps operation

3.3V single power supply

High performance and cost-effectiveness

850nm VCSEL and PIN photodetector, 550m transmission

Compliant with SFP MSA and SFF-8472 requirements, and equipped with a duplex LC connector

Digital diagnostic monitoring

Compatible with SONET OC-24

Working box temperature: 0 to 70°C, -40 to 85°C

Compliant with RoHS (Lead-free)

  • 商品详情
  • 资料下载(PDF)

光模块01

光模块02

光模块03

Description

SFP transceivers are high-performance and cost-effective modules that support 1.25Gbps and a MMF transmission distance of 550m. The transceiver consists of three parts: an 850nm VCSEL transmitter, a PIN photodiode integrated with a transimpedance preamplifier (TIA). All modules meet the safety requirements of Class 1 lasers. The transceiver is compatible with the SFP Multi-Source Agreement (MSA) and SFF-8472. For additional information, please refer to the SFP MSA.

Applications

• Gigabit Ethernet

• Gigabit Fibre Channel

• Switch-to-switch interface

• Switched backplane applications

Order Information

Part number

Product Description

HZTS1SR

SFP, 1.25Gbps, 850nm, MM, 550m, 0ºC~+70ºC, With DDM

HZTS1SRI

SFP, 1.25Gbps, 850nm, MM, 550m, -40ºC~+85ºC, With DDM

光模块04

光模块05

光模块06
