physical dimensions

Thin specification: 6.127 inches x 2.712 inches

(approximately 155.6mm x 68.9mm)

Host bus type

PCIe 4.0 x8 lane (backward compatible with PCIe 3.0/2.0)

I/O processor

SAS3916 12Gb/s Tri‑Mode RAID‑on‑Chip (RoC) Controller

RAID level support

RAID 0/1/5/6/10/50/60 and JBOD modes

Equipment support capability

- SAS/SATA devices: 240

(some documents indicate support for 1024;

subject to the latest manufacturer specifications,

specific scenario limits to be supplemented) - NVMe devices: 32

Data transmission rate

- SAS interface: 12 Gb/s - PCIe interface: 16 GT/s (Gen4 standard)

Cache configuration

8GB DDR4 cache (with CacheVault CVPM05 protection module)

internal interface

2 x8 SFF-8654 SlimSAS connectors

management software

LSA management suite / StorCLI command-line utility /

UEFI HII interface

Certified compatibility

Supports mainstream operating systems including Windows,

VMware, Linux, Citrix XenServer, and FreeBSD, with RoHS, FCC,

CE certifications.

Tri-mode technology support

Supports concurrent operation of NVMe/SAS/SATA protocols,

compliant with SFF-TA-10001 (U.3) and UBM specifications.

Environmental specifications

-Working temperature: 0 ° C to 55 ° C

-MTBF:>3 million hours (40 ° C environment)

-Working humidity: 20% -80% non condensing

core chip

SAS3916 RoC controller with tri‑mode SerDes supporting

NVMe/SAS/SATA protocols

Power consumption indicator

Typical working power consumption 8.9W

Management tool extension

Support StorCLI command-line tools and UEFI HII graphical interface
