NVIDIA MCX623105AC-VDAT

￥1

型号： MCX623105AC-VDAT

加入购物车

产品特征

1/10/25/40/50/100/200 Gb/s Ethernet, PAM4/NRZ

PCIe Gen 4.0 x16 host interface

Crypto Enabled

Message rate up to 215 Mpps

Latency < 0.8 microseconds

Flexible programmable pipeline for new network flows

Multi-host with advanced QoS

ASAP2 – Accelerated Switching and Packet Processing for virtual switches/routers

Overlay tunneling technology

In-line IPsec and TLS encryption acceleration

Static data encryption acceleration (Secure Static Data)

Hardware root of trust and secure firmware update

Supports x86, Power, ARM

ODCC compatible

商品详情
资料下载(PDF)

恒正同创第二次版详情页_01 恒正同创第二次版详情页_02 恒正同创第二次版详情页_03

The ConnectX‑6 Dx SmartNIC is the industry’s most secure and advanced cloud network interface card, accelerating mission‑critical data center applications such as security, virtualization, SDN/NFV, big data, machine learning, and storage. It offers up to two 100 Gb/s ports or one 200 Gb/s Ethernet port, and delivers the highest return on investment (ROI) of any intelligent network interface card.

Model Name	Speed	Interface Type
MCX623105AC-VDAT	10/25/40/50/100/200GbE	Single-port QSFP56
Application Field	Hardware Interface	ROCE
Ethernet	PCIe 4.0 x16	Supported
Chip Type	ROHS	Operating System
ConnectX-6 Dx EN	Yes	RHEL/CentOS, Windows, FreeBSD, VMware, OFED, WinOF-2
Link Speed
16.0 GT/s
